Grab Bars Available in Multiple Sizes

The separately purchasable mounting kit is used for installing the wall bracket on solid walls such as concrete or high-quality brick. The kit should NOT be used on soft walls such as plaster, wood, or aerated concrete.

The mounting kit (optional) includes the following components:

1. 4 pieces Nylon plugs Fischer, Ø 10 x 60 mm
2. 4 pieces Lag screws Din 571 A2, 8 x 80 mm
3. 4 pieces Stainless steel washers Din 125
4. 4 pieces Protective cap nv 13

Installation of the wall bracket using the mounting kit:

1. Hold the wall bracket in the desired position on the wall and mark through the holes in the bracket with a pencil.
2. Then drill 4 Ø 10 mm holes at least 80 mm deep into the wall. Next, insert the nylon plug (A) using a hammer. It is crucial that the plug does not move and has not been damaged during installation.
3. Attach the washers (C) to the lag screws (B), then secure them through the holes in the wall bracket and tighten firmly.
4. Place the protective cap (D) over the 4 screw heads.

IMPORTANT! Before using the wall bracket, ensure that it cannot move even under high load. It is the installer’s responsibility to ensure that the bracket is securely mounted and that the wall type and condition are suitable for installing the bracket with this mounting kit.
